TO EACH RECORD ITS OWN EQ CURVE
The PH-5 allows a selection of the most appropriate equalization curve for each vinyl record, directly on the touch display: RIAA, DECCA LONDON, and AMERICAN COLUMBIA. Thanks to our proprietary technology inspired by Georg Neumann (the producer of the famous Neumann Disc Cutting Lathe ), each curve can be “Enhanced” to extend the frequency response up to 50kHz, improving even further the stage, dynamics, and resolution when required.
DEDICATED EXTERNAL POWER SUPPLY
To maximize the performance of the PH-5 we also developed the dedicated, external super inductive power supply that allows the phono stage to achieve its fullest potential, reaching an even higher degree of musical realism, better dynamics, and greater three-dimensionality sound.
EQUALISATION CURVE CONTROL
3 EQ curves (RIAA, Decca London, American Columbia) all with Enhanced option
INFRASONIC FILTER
10Hz/36dB octave
FREQUENCY RESPONSE
20Hz -20kHz ± 0.3dB
Enhanced 20Hz-50kHz ± 0.3dB
THD (Total Harmonic Distortion)
<0.05% @ 1kHz
SIGNAL TO NOISE RATIO
89dB
DYNAMIC RESPONSE
105dB
ANALOGUE INPUT
1x RCA stereo MM/MC
INPUT SENSITIVITY
0.1mV MC up to 10.0mV MM
INPUT IMPEDANCE
9 options [10Ω, 22Ω, 47Ω, 100Ω, 220Ω, 470Ω, 1000Ω, 22kΩ, 47kΩ]
GAIN
MM= 40dB
MC= 60dB
with 4 options [0dB, + 3dB, ± 6dB]
CAPACITANCE (MM ONLY)
220pF
AUDIO OUTPUTS
1x unbalanced RCA
1x balanced XLR
OUTPUT IMPEDANCE
50Ω
DIMENSIONS
200W | 80H | 260D mm
290W | 180H | 390D mm – boxed
WEIGHT
Kg. 1.2 – net
Kg. 2.2 – boxed
Black varnished iron and aluminium.
Finns endast i svart utförande.
